Class1000 Pharmacy Softwall CleanRoom With HEPA Filtration
Quickly detail : softwall Cleanroom
External size : 8000x4500x3100mm
Internal Size: 7900x4400x2700mm
Purification rank: Class1000
HEPA filter efficiency: 99.999%@0.3um
Laminar flow: vertical
Air speed :0.3-0.6m/s
Fan filter unit : 8 sets 1175x575x350mm
Power: 220V/50HZ 110V/60HZ
Wall : Plastic curtain
Pharmacy softwall cleanroom is a local air purification equipment to provide high- clean environment, is a clean room which the
most quickly and easily create. Softwall cleanroom main consist of cabinet, fan, prefilter and HEPA filter, damping layer, lamps and other components. It can be suspended, but also can be ground support, compact structure, easy to use. Can use single or multiple connections to compose of banded clean area.
pharmacy softwall cleanroom interior cleanliness can be reached100-100000class level, in order to reduce structural costs of clean shed, keling changed the traditional concept of clean shed design, take a modular integrated design concept ,
this structure has a variety of separate clean area, for some areas of general clean class level clean room that required high clean class level do local creation to reduce costs, thus making the workers and equipment, products effectively isolated, can minimize the pollution, thereby increasing the rate of qualified products.
Applications: softwall Cleanroom
Food industry, aerospace, life sciences, biotechnology, medical devices, plastic injection module, electronics assembly or hospital pharmacy
Operating features; softwall Cleanroom
1: the softwall cleanroom can offer the part of high clean environment ,it can be installed on the top of the place
that need to clean.The air that come out from the FFU will be filtered by the HEPA filter ,then the clean
air enter into the work zone vertically to insure the purification requirement
2. the noise less than 60db,the air velocity is 0.3-0.55m/s
3. Material: the frame of clean booth is made of aluminun alloy, the board can be choosen plexiglass,
Acrylic sheet, PVC plate. It is also can be made of PVC anti-static blinds.
4. it can be used by single and also can be connected to clean area in strip
5. purification rank : in work area : 0.3um dust ((FS209E100-10000class )
Clean booth offer the part of high clean environment
Technical Parameter: softwall Cleanroom
| MODEL | KEL-LFB |
| Ex size (mm)
(W*D*H) | 8000x4500x3100mm |
| In size (mm) | 7900x440x2700 |
| Purification rank | Class1000 -(FS209E USA) |
| HEPA filter | Efficiency : 99.99% @ 0.3um - 99.999% @ 0.12um (MPPS) |
| Pre-filter | Efficiency : 85% @ 5um |
| Control system | PC control system / promised speed by control box |
| Pressure Gauge | American Dywer pressure |
| Noise | <50-55 dB (test point distance is 1m) |
| Air velocity
(m3/h) | 0.2-0.5m/s Adjustable (test point distance is 30cm) |
| Frame material | stainless steel/steel with power coated/Cast aluminum profile |
| Wall frame | Tempered glass / PVC anti-static curtain (option) |
| Fan | EBM Fan /Taiwan fan/ Domestic fan (option) |
| Power suppler | AC110/220v 50HZ/60HZ |
Customer’s design is available.
